Technical Specification
Rated Power Bridge Mode 8Ω 450 Watts @ 1KHz at < 0.1% T.H.D.
Rated Power (2 x 4Ω) 225 Watts per channel @ 1KHz at < 0.1% T.H.D. both channels driven
Rated Power (2 x 8Ω) 150 Watts per channel @ 1KHz at < 0.1% T.H.D. both channels driven
Input CMRR > -65dB @ 1KHz
Power Bandwidth 10Hz - 30KHz ; 0, -0.5dB at rated 80 Watts 8Ω power
T.H.D. (2 x 4Ω) < 0.05% @ 150 Watts per channel from 20Hz - 20KHz
T.H.D. (2 x 8Ω) < 0.05% @ 150 Watts per channel from 20Hz - 20KHz
Rated Power (1 x 4Ω) 270 Watts @ 1KHz at < 0.1% T.H.D.
Rated Power (1 x 8Ω) 180 Watts @ 1KHz at < 0.1% T.H.D.
Minimum Load Impedance 4Ω
Maximum RMS Voltage Swing 45 Volt
Frequency Response 10Hz - 100KHz ; +0, -3dB at 1 Watt
Phase Response +5 to -15 from 20Hz to 20KHz
Input Impedance 10KΩ balanced
Cooling Two temperature dependant variable speed 40 mm. high output DC fans
Controls Two front panel attenuators, rear panel mode switch and gain select switch
Voltage Gain 0.775V, 32dB or 26dB
Crosstalk > -60dB @ 1KHz at rated power @ 8Ω
Hum and Noise > -106dB, 'A' weighted referenced to rated power @ 8Ω
Slew Rate > 22V/us
Dampling Factor (8Ω) > 500:1 @ 20Hz - 1KHz
Indicator LEDs 2 clip, 2 signal presence, 1 bridge, 1 active status/protection
Protection Thermal, DC, turn-on bursts, incorrect loads
Connectors XLR, speakon and binding post speaker output
Construction 16 ga. stell
Dimensions [HxWxD] 44 x 483 x 350 mm.
Net Weight 9 kg.
