Rated Power (8Ω, @ 1kHz)2 x 600W
Rated Power (4Ω, @ 1kHz) 2 x 1000W
Max Gain 39dB
Amplifier Type H
Current Consumption (1/8 power 4Ω speaker) 2.2A @230V
Max Current Consumption (1/8 power 4Ω speaker) 5A @230V
THD (@1kHz) <0.025% @8Ω, 20Hz-20kHz
IMD (@60Hz/7kHz 4:1) <0.05% @8Ω, 60Hz/7kHz 4:1
Frequency Response <± 0.5dB, 20Hz-20kHz
Phase Characteristics <± 15°
Damping Factor >300:1
Resolution >80 dB
S/N Ratio >106dB(1kHz, A weight)
Input Sensitivity 0.775V
Input Impedance unbalance>10kΩ, balance >20kΩ
Input Connectors 2 x XLR
Output Connector 2 x XLR+2 x NL4+4 x Binding post
Power Supply AC 220-230V 50Hz/60Hz
Cooling airflow from front to back
Environment Temperature ) -10℃--40℃(working) -25℃--80℃(storehouse）
