CYP CLUX-11CD HDMI TO HDMI/TOSLINK/RCA AUDIO EXTRACTOR
CYP CLUX-11CD HDMI TO HDMI/TOSLINK/RCA AUDIO EXTRACTOR
|
- ยี่ห้อ : CYP
- รุ่น : CLUX-11CD
- HDMI Audio Extractor
- Compliant with HDMI, HDCP 1.2 and DVI 1.0
- Supports HDMI audio sampling rates up to 192 kHz
- Supports Optical S/PDIF sampling rates up to 48 kHz
- Supports TMDS clock frequency rate 225 MHz
- Supports high-bit-rate (HBR) audio
- No HDMI output connection is required to receive audio at the analog and optical outputs
- Maximum input and output HDMI cable length can run up to 15 meters at 1080p at 8-bit resolution
- Low power consumption
- Supports EDID management for audio formats, can switch among built-in EDID (LPCM 2CH/Bitstream) and external EDID (TV)
- Supports 3D signal
Specification
- Inputs 1x HDMI [1x Uncompressed AV and Data]
- Outputs 1x HDMI [1x Uncompressed AV and Data]
- 1x TOSLINK [1x Optical 2 Channel LPCM]
- 2x RCA [1x Stereo (L/R)]
- PSU: 5V/1.2A
- Dimensions 91mm [W] x 86mm [D] x 34mm [H]
- Net Weight 107g
- ราคาปกติ : 5,590.00 ฿
- ราคาพิเศษ : 4,690.00 ฿
-
|
| |
|
| |
|
