Digital data processing controlled by microprocessorand microcontroller.
• 2.2K,2.5K,3.3K,5.5Kw dimming or Relay per ch.
• DMX-512 digital control protocol
• Solid state thyristor phase control(scr[2/Ch]or triac)
• ‘DMX-In’ LED for DMX-512 signal indication
• Up to 32 program recalling
.• Digital DMX start channel display
• Dimming or switching each channel can be set to be a switching
only (non-dimming)
• Single or three phase operation
• Dimmer will hold last DMX value for a set time should control
data be interrupted
• 1024-step fade resolution for all fade and cross-fade functions
• Data bus including: DMX, Rs485
• RS485 Interface: LMX, RS232 Interface to PC
• Variable fade rates from 0 seconds to 1 hours
• Individual channel bypass to full MCB protection
• Dimmer can be setup from Pc and Internal Function
• Function setting Room combine at 5 Room
• Pre-heat facility
• Internal temperature controlled DC fan
• Soft turn-on characteristic
• Built-in test facilities
• Dimmer curve set for linear relationship between
the control input and output power
• Over-temperature cut outs
• program duration & fade rate
• 24-hr 7-day in-built event timer (battery backed)
• Permanent memory in case of power failurepre-set scenes are not lost
• Temporary circuit adjustment without save
• Security Settings – Lock key
• I/O for control of: non-lighting equipment, curtains,Shades, blinds, water features, security and alarm,Systems, etc.
• Arc-free relay switching
• AC dual-motor interlocking (Dry contact)
• Electrician-friendly installation
• Compliant with CE and EMC standard
