1. DMX 512 / 1990, Up To 1024 Dmx Channels,Output With Optical Isolation Supports
2. Up To 120 Intelligent Fixtures Or 120 Dimmers.
3. Personality In Avolites Perl r20 Format. Shape Generator With 180 Built-In Shapes,Including Circle,Spiral And Rainbow,Etc.
4. Shape Parameters,Such As Wide,Speed, a Spread,Wave And Direction,All Can Be Set Up Individually.
5. 100 Palettes In 4 Modes.
6. 120 Playbacks Can Be Stored As Scene,Chase Or Cue List.
7. Up To 600 Steps Can Be Stored In a Chase.
DMX channel 1024
Power AC100V-240V/50-60Hz
Channels for each fixture 40 primary + 40 fine tune
Library Avolite Pearl R20 library supported
Time control of Scenes Fade in/out, LTP slope
Shape generator Shapes of Dimmer, Pan/Tilt, RGB, CMY, Color, Gobo, Iris and Focus
