Designed to support live mixing applications, the CVM1224FXUSB 12-Channel Professional Audio Mixer delivers VEGA effects and fine level adjustment with the 60mm faders. Featuring the same 3-band equalization and AUX & EFX bus flexibility found in all Cerwin-Vega! professional audio mixer line, this 12-channel mixer is everything you need to take control of your sound.
4 mono and 4 stereo line input with 6 XLR microphone inputs
MAIN L/R ¼' jack and XLR output
ALT 3-4 ¼' jack output
TAPE IN stereo RCA jacks for connection to a CD or MP3 player
REC OUT stereo RCA jacks for connection to a recorder
¼' Stereo headphone & Balanced ¼'control room out
3-Band channel equalizer providing ±15 dB (HF, LF) and ±12 dB (MF) per channel
Peak LED indicator to check on the signal input of each microphone channel
Individual channel and main level control using 60mm faders
Gain (trim) level control with sensitivity markings for both microphone and line inputs
Low Cut (HPF) switch @75Hz to eliminate background microphone rumble
AUX and EFX controls to adjust the level of the signal sent to the respective bus
PAN control (mono channel) to position the signal across the master left and right bus
BALANCE control (stereo channel) to adjust the level between left and right signals
Switchable Phantom power (+48V) switch for safe and easy connection of condenser microphones
Level control for headphone and control room connections
PRE/POST switch to set the AUX signal as pre- or post-fader for foldback /monitoring mix or to preserve the wet-to-dry ratio on AUX sends
PFL (pre-fade listen) switch with adjacent indicator to allow the engineer to listen to each channel before it reaches the main mix
Built-in VEGA-effects 24-bit digital signal processor with 100 selectable programs including reverb, echo, chorus and flange
100mm VEGA-effects master fader and remote footswitch on/off control for effects return
16-bit, 44.1kHz USB connection for computer playback and recording (class compliant)
Detachable rack ears for mounting in a standard 19' rack enclosure
