RCF L-PAD 24CX USB 24 CHANNEL MIXING CONSOLE WITH EFFECTS
เข้าชม 997
| ตอบ 0
RCF L-PAD 24CX USB 24 CHANNEL MIXING CONSOLE WITH EFFECTS
ยี่ห้อ : RCF
รุ่น : L-PAD 24CX USB
The L-PAD 24CX USB is a 24-channel, 4-bus mixer with 18 Mic/Line, 4 Stereo Input, 4 Group out, EQ, 8 single-control compressors and internal effects, for any live performance reinforcement. It features 18 transparent sound, ultra-low noise microphone inputs with balanced XLR connector, or alternatively 16 mono line input with insert send/return, a three-band EQ with a sweepable mid frequency on 16 channels, 4 channels of stereo inputs with 4-band fixed EQs, and 4-groups assignable sub mixes, 60mm long-live extra smooth faders and four AUX sends per channel (2 Pre/Post switchable pots). The L-PAD 24CX USB gives you all the features you need to mix any professional live performance.
18 MIC/LINE inputs, 4 STEREO inputs
8 single-control dynamic compressors (Ch. 1-Ch.8)
4 STEREO AUX returns
3-band EQ with sweepable MID Frequency on microphone channels
4-band fixed EQ on stereo line channels
4 AUX sends per channel: 2 PRE/POST faders switchable
4-GROUP MIX
24-bit DSP effects for 99 presets
USB port for PC audio recording and playback
Frequency Response: 20Hz ÷ 20kHz Total Harmonic Distortion (THD+N): 0,03%%
Gain range: 0dB ÷ -50dB
input Mic: 18
Input Mono Line: 16
EQ BANDS on MONO channels: 3 Sweepable mid frequency 100Hz-8kHz EQ BANDS on STEREO channels: 4 +/-15dB @ 12kHz - Shelving, +/-15dB @ 3kHz, +/-15dB @ 500Hz, +/-15dB @ 80Hz - AUX send : 2 PRE/POST 1 + 1 FX POST
