A-3248DMZ is a high performance yet cost-effective mixer power amplifier equipped with MP3,Bluetooth function and Zone selection. Ideal for broadcasting, paging, or background music in schools, offices, shops, houses of worship and large ballrooms.
Rated Output 480 W
Power Consumption 99 W (AC operation at 1/8 maximum output without clip)
Frequency Response 50 - 20,000 Hz
Input MIC 1: 1 mV (-60 dB*), 600 Ω, balanced, phone jack, selectable to RJ45
MIC 2-3: 1 mV (-60 dB*), 600 Ω, balanced, phone jack
MIC 4: 1 mV (-60 dB*) 600 Ω, balanced, phone jack, selectable to AUX 1
AUX 1: 100 mV (-20 dB*), 10 kΩ, unbalanced, RCA pin jack, selectable to MIC 4
AUX 2: 100 mV (-20 dB*), 10 kΩ, unbalanced, RCA pin jack
MP3: LED Display, Support USB, SD/MMC card (up to 32GB), Bluetooth, Radio FM, Record
Output Speaker out: Speaker Output in screw type terminal
Direct line (selectable): 21 Ω (100 V) or 4 Ω
Rec out: 0 dB*, 600 Ω, unbalanced, RCA pin jack
5-zone selector (all zones simultaneously selectable)
Phantom Power DC +21 V (MIC 1)
S/N Ratio Over 60 dB
Total Harmonic Distortion Under 1% at 1 kHz, 1/3 rated power
Tone Control Bass: ±10 dB at 100 Hz
Treble: ±10 dB at 10 kHz
Muting MIC 1: Mutes other input signals by 0-30 dB attenuation
Indicator Power, Signal , Peak, Protect
Ventilation Fan Cooling
Finish Panel: ABS resin, black
Case: Steel plate, black
Dimensions 420 (W) × 100.9 (H) × 357 (D) mm
Weight 5.0 kg
รุ่นอื่น มีดังนี้
A-3248D-AS Digital PA Amplifier (480w.) เครื่องละ 19,500 พิเศษ 16,575 บาท
A-3248DM-AS Digital PA Amplifier +MP3 (480w) เครื่องละ 22,800 พิเศษ 19,380 บาท
Mixing,Pre-Amplifier - TOA
