4 universal Y/CV, Pb/C, Pr (composite, s−Video and component) 1 Vpp/75Ω on RCA connectors;
2 UXGA on a 15−pin HD connector (VGA through UXGA);
2 HDMI connectors;
1 USB connector;
For each universal input there is a corresponding (unbalanced) audio stereo input (1V nom./25kΩ minimum) and digital stereo S/PDIF input (32kHz to 96kHz sample frequency/75Ω) on RCA connectors;
For each UXGA input there is a corresponding (unbalanced) audio stereo input on a 3.5mm mini jack connector.
OUTPUTS:
1 HDMI connector;
1 UXGA format on a 15−pin HD connector;
1 unbalanced audio stereo output (1V nom./50Ω) on RCA connectors;
1 digital stereo S/PDIF output (32kHz to 96kHz sample frequency/75Ω) on an RCA connector.
