The TOA Wireless Antenna Distributor WD-5800 is designed to be used in conjunction with VHF/UHF band system. It comes with two distribution channels, in which two input signals are mixed and distributed to four outputs.
Power Source AC mains (supplied AC adapter must be used)
Power Consumption 25 W or less
Current Consumption 1.6 A (12 - 15 V DC)
Frequency Range VHF/UHF
Antenna Input 2 inputs per distribution channel (front × 1, rear × 1),
75 Ω, BNC (phantom powering for antenna)
Antenna Output 4 outputs per distribution channel, 75 Ω, BNC
DC Power Supply 4 output (each output: 12 V DC/250 mA)
(Output voltage of this unit depends on that of AC adapters.)
Indicator Power lamp
Operating Temperature -10℃ to +50℃
Operating Humidity 30 % to 85 %RH (no condensation)
Finish Panel: Aluminium, black, paint
Case: Steel, black, paint
Dimensions 420 (W) × 44 (H) × 214 (D) mm
Weight 2 kg
Accessory AC adapter*1 x 1, Power cord (2m)*1 x 1, DC cable x 4, Rubber foot x 4
Option Rack mounting bracket: MB-15B
