TOA YW-4500 wall mount UHF Wireless Antenna 550 - 932 MHz, UHF
TOA YW-4500 wall mount UHF Wireless Antenna 550 - 932 MHz, UHF
|
- ยี่ห้อ : TOA
- รุ่น : YW-4500
- The wireless antenna YW-4500 has been designed for UHF band wireless system. Cable loss can be compensated for by a built-in RF signal booster. The YW-4500 in a dipole antenna designed to be installed in doors. Use the coaxial cable with 75 Ω impedance.
| Power Source |
7 - 12 V DC (supplied from amplifier or tuner) |
| Current Consumption |
15 mA or less |
| Receiving Frequency |
550 - 932 MHz, UHF |
| Dipole Ratio Relative Gain |
8 dB or more (780 MHz) |
| VSWR |
3.0 or less |
| Output Impedance |
75 Ω |
| Mounting Hole Pitch |
83.5 mm (dimensions for wiring box) |
| Operating Temperature |
-10 %%dC to +50 %%dC |
| Operating Humidity |
30 % to 85 %RH (no condensation) |
| Finish |
AES resin, off-white |
| Dimensions |
105 (W) × 140 (H) × 126 (D) mm |
| Weight |
270 g |
| Accessory |
M3.5 screw for wiring box…2, Tapping screw (M4) for wooden wall…2,
RG-6/U or RG-11/U sleeve…1 |
- ราคาปกติ : 3,980.00 ฿
- ราคาพิเศษ : 3,390.00 ฿
-
|
| |
|
| |
|
